CM1M9-2F - Power Cable for SRLM/S

Description

The CM1M9-2F is a 2 conductor power cable for SRLand legacy RBSTintegrated modules

M9 connector is Binder 99-0402-00-02

Part Number	Description
CM1M9-2F-2000	Standard 2m M9 female power cable
CM1M9-2F-xxxx	xxxx - defines cable length in mm Example 3ft cable → CM1M9-2F-914 50cm cable → CM1M9-2F-500 It not recommended for the cable to exceed 5m due to possible injection of noise on the serial line.

Part Number

Description

CM1M9-2F-2000

Standard 2m M9 female power cable

CM1M9-2F-xxxx

xxxx - defines cable length in mm

Example

It not recommended for the cable to exceed 5m due to possible injection of noise on the serial line.
