CM1-T
CM1-T
Breadcrumbs

Datasheets and Downloads

CM1-T Configuration Tool

CM1TApp.png CM1-T Configuration Tool.exe

EtherNet/IP Support Files

eds icon.png CM1-T EIP_V13.eds

Allen-Bradley Specific

zip.png CM1-T_AOIs.zip

  • Add-On Instructions

  • User Data Types

  • Example Application

CM1-T Library

library icon.png CM1T.compiled-library

See the CM1-T Library documentation page for additional information.

The CM1-T library can be use in all IEC 61131-3 development environments such as Codesys, Schneider's Machine Expert, WAGO’s e!COCKPIT, Beckhoff's TwinCAT and more.

The CM1-T Library can be used with the following protocols

  • EtherNet/IP

  • Modbus/TCP

  • TCP/IP

  • UDP

Version History

Version

Changes

V1.0.1.0

  • Function blocks added

    • MC_ReadDigitalInput

    • MC_ReadDigitalOutput

    • MC_WriteDigitalOutput

V1.0.0.2

  • Updated WORD structure in DATA_IN and DATA_OUT for simplified Modbus TCP mapping

V1.0.0.1

  • Initial release

MCAD

3D Models

For additional 3D formats please contact Myostat support (support@myostat.ca).

CM1-T-17L30D MCAD.zip

CM1-T-17S30D MCAD.zip

CM1-T-23S30D MCAD.zip

CM1-T-23L20D MCAD.zip

Datasheets

CM1-T-17S30D / CM1-T-17L30D

CM1-T-17X30D-XX-X-rev0.pdf

CM1-T-23S30D / CM1-T-23L20D

CM1-T-23XX0D-XX-X-rev0.pdf
